General

• Device Interfaces:
  • 1 × Gigabit Ethernet PoE LAN (uplink)
  • 3 × Gigabit Ethernet LAN (downlink, uno PSE out)
  • 1 × Botón Reset
• LED: Power / Status
• Antenna Type: 2 × antenas internas dual-band
• Wi-Fi Data Rates:
  • 5/GHz hasta 2402/Mbps
  • 2.4/GHz hasta 574/Mbps
• IEEE Standards:
  • IEEE 802.11ax/ac/n/g/b/a
  • IEEE 802.3u/ab/an
  • IEEE 802.3at PoE

Seguridad

• Security Protocol:
  • WPA / WPA2 / WPA3 Personal y Enterprise
  • SSID broadcast disable
  • Control de acceso por MAC
  • WEP 64/128 bits
  • Enhanced Open
  • Servidor RADIUS interno

Wi-Fi / Radio

• Operating Frequency:
  • 2.4–2.483/GHz
  • 5.15–5.35/GHz
  • 5.47–5.85/GHz

Gestión

• Device Management:
  • Nuclias Connect
  • Web (HTTP/HTTPS)
  • Telnet / SSH
  • SNMP

Dimensiones y entorno

• Dimensions: 195.68 × 120.72 × 40.2 mm
• Operating Temperature: 0 a 40/°C
• Storage Temperature: –20 a 65/°C
• Operating Humidity: 10% – 90% sin condensación
• Storage Humidity: 5% – 95% sin condensación

Certificaciones

• CE
• FCC

Contenido de la caja

• DAP-X3060W
• Wallmount Bracket
• Tornillos
• Quick Start Guide
